Reference Part Number:

replacement for Firestone W01-M58-6345, W01-M58-8775,1T19LB 8, 1T19LB8, 1T19L7, W01M588108,1T19L-7, 1T19LB-8, CO1-M58-1162
replacement for ContiTech C1R14-873, C1R14873, C1R14873, 810MB(810N/810N), 72307
replacement for Goodyear 1R14 716, 1R14716, 1R14 820, 1R14820, 1R14 824, 1R14824, 566 28 3 548, 566283548, 566 28 3530, 566283530, 566 28 3539, 566283539
replacement for Volvo 1080 707, 1080707
replacement for Dunlop D13B20, D13B01, 00984AAP, 00984AAP

Other parts number:
for Hendrickson: 506 243, 506243, 50624301,785168
for Airtech: 130022, 3810C
for Blacktech: RML7921C
for CF Gomma: 87413 1, 874131,1T19E 1, 1T19E1
for Fabio: 34810C, 34810C, 400093
for Neotec: ABM 722 34A35, ABM72234A35
for Phoenix: 1D28A-2, 1D28A 2
for Primeride: 5810AP03, 5810AP03, 1R14-716, 1R14-820, 1R14-824, 566-28-3-548, 566-28-3-530, 566-28-3-539
for Springride: 1R14-716, 566-28-3-548
for Taurus: KR621 26, KR62126
for Vibracoustic: V1D28A-2, V1D28A2
for Sampa: 34810 K, 34810K
for DAF: 1 384 273, 1384273
for Granning: 15635
for Neway: 21215632
for Renault: 5 000 452939, 5000452939
for SAF-Holland: 2 228 0002 00, 2228000200, 2 228 2102 00, 2228210200, 2.228.2202.00,2 228 220200,2.228220200,2.228.2402.00,2228 240200,2228240200,2.228.2602.00,2228 260200,2228260200,2.229.0002.00,2229000200,2229000200
for Trailor: 650 4646G,6504646G
for Trouillet: HB 10 315,HB10315
for Weweler: 2120 8082,21208082,US 00622,US00622,US 07337,US07337,US 87413,US87413,US 874131,US874131
for SAF-Holland: 2918
for Scania: 1723502
for Meritor: 2120 8082,21208082,2121 5632,21215632
for Schmitz: 613589

Specification:

Top plate screw (nut) teeth: M12
The screw center distance of the top cover plate: 159 mm / 6.26 inch
Screw (nut) teeth of the bottom cover plate: M14x2
Air hole/air inlet: M22x1.5
Top plate diameter: 287 mm / 11.3 inch
Diameter of the bottom cover: 260 mm / 10.24 inch
Stroke: from 180 mm/ 7.1 inch to 21.65 inch / 550 mm
Intern Jounce Bumper: No
Quantity: 2 Pieces
Condition: Brand New
Material: Natural rubber
Piston Material: SPHC Steel

Features:

1、Highest leak test ratio: 100% Air Tightness Testing.
2、Tested over 4,000,000 times, most air springs are only tested 1,000,000 times.
3、Temperature Range ≥-40°F/≤158°F: Premium Natural Rubber Material.
4、Exceeds OEM requirements for 4.5-5.0 mm thick rubber.
5、12.9 grade high strength steel studs.
6、Withstand 2Mpa of air pressure before the rubber burst.
7、Careful evaluation of OEM specifications.
8、Strict quality control.
9、Sturdy & Durable Material.
10、Reduces Damage of Trailer, Cab And Truck Body.
11、Reduce driver discomfort and dangerous fatigue, improve driver safety.
12、Allow perfect load equalization between axles. Provide constant-level hauling.
13、Increase life of tires and brake linings.
14、Substantially reduce breakage and maintenance of other vehicle components.

Notice:

- These air suspension bags are aftermarket ones. They will replace the original air springs.

-Instruction is not included. Professional installation is recommended

-Contact us please for whatever we can help
